Asus ROG Strix B660-A Gaming Wifi Socket LGA 1700 Ddr4 Gaming Motherboard

Description

Asus ROG Strix B660-A Gaming Wifi Socket LGA 1700 Ddr4 Two-Way AI Noise Cancelation, AI Cooling, AI Networking Gaming Motherboard

Product Description

Dominate gaming with the Asus ROG Strix B660-A Gaming Wifi motherboard. LGA 1700 socket, DDR4 support, and premium features ensure peak performance. Immerse in seamless connectivity and gaming prowess, all packaged in a sleek design that enhances your gaming setup.

Product Specifications

• Brand: Asus
• Model: ROG Strix B660-A
• CPU:
• Intel® Socket LGA1700 for 12th Gen Intel®Core™, Pentium® Gold and Celeron® Processors*
• Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
• Chipset: Intel® B660 Chipset
• Memory:
• 4 x DIMM, Max. 128GB, DDR4 5333(OC) /5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory*
• Dual Channel Memory Architecture
• OptiMem II
• Graphics:
• 1 x DisplayPort**
• 1 x HDMI® port***
• Expansion Slots:
• Intel® 12th Gen Processors
• 1 x PCIe 5.0/4.0/3.0 x16 slot(s)*
• Intel® B660 Chipset**
• 1 x PCIe 3.0 x16 slot (supports x4 mode)*
• 2 x PCIe 3.0 x1 slots
• Storage:
• Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*
• Intel® 12th Gen Processors
• 2_1 slot (Key M), type 2242/2260/2280/22110
• – Intel® 12th Gen processors support PCIe 4.0 x4 mode.
• Intel® B660 Chipset
• 2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode)
• 2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
• 4 x SATA 6Gb/s ports***
• Ethernet:
• 1 x Intel® 2.5Gb Ethernet
• ASUS LANGuard
• Wireless & Bluetooth:
• Wi-Fi 6
• 2×2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
• Supports 2.4/5GHz frequency band
• Bluetooth v5.2
• USB
• Rear USB (Total 9 ports)
• 1 x USB 3.2 Gen 2×2 port(s) (1 x USB Type-C®)
• 1 x USB 3.2 Gen 2 port(s) (1 x Type-A)
• 3 x USB 3.2 Gen 1 port(s) (2 x Type-A + 1 x USB Type-C®)
• 4 x USB 2.0 port(s) (4 x Type-A)
• Front USB (Total 6 ports)
• 1 x USB 3.2 Gen 2 connector (supports USB Type-C®)
• 1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports
• 1 x USB 2.0 10-1 pin header + 1 USB 2.0 4 pin hearer support additional 3 USB 2.0 ports
• Audio:
• ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
• – Impedance sense for front and rear headphone outputs
• – Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
• – High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
• – Supports up to 32-Bit/384 kHz playback
• Audio Features
• – SupremeFX Shielding Technology
• – Savitech SV3H712 AMP
• – Premium audio capacitors
• – Audio cover
• * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
• Back Panel I/O Ports
• 1 x USB 3.2 Gen 2×2 port(s) (1 x USB Type-C®)
• 1 x USB 3.2 Gen 2 port(s) (1 x Type-A)
• 3 x USB 3.2 Gen 1 port(s) (2 x Type-A + 1 x USB Type-C®)
• 4 x USB 2.0 port(s) (4 x Type-A)
• 1 x DisplayPort
• 1 x HDMI® port
• 1 x Wi-Fi Module
• 1 x Intel® 2.5Gb Ethernet port
• 5 x Audio jacks
• 1 x BIOS FlashBack™ button
• Internal I/O Connectors
• Fan and Cooling related
• 1 x 4-pin CPU Fan header(s)
• 1 x 4-pin CPU OPT Fan header(s)
• 1 x 4-pin AIO Pump header(s)
• 3 x 4-pin Chassis Fan header(s)
• Power related
• 1 x 24-pin Main Power connector
• 1 x 8-pin +12V Power connector
• 1 x 4-pin +12V Power connector
• Storage related
• 3 x M.2 slots (Key M)
• 4 x SATA 6Gb/s ports
• USB:
• 1 x USB 3.2 Gen 2 connector (support USB Type-C®)
• 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
• 1 x USB 2.0 10-1pin header + 1 USB 2.0 4pin header support additional 3 USB 2.0 ports
• Operating System: Windows® 11 64-bit, Windows® 10 64-bit
• Form Factor: ATX Form Factor
• 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
• BIOS: 192 Mb Flash ROM, UEFI AMI BIOS
• Features:
• Intel® LGA 1700 Socket: Ready for 12th Gen Intel Core™, Pentium® Gold and Celeron® processors
• Optimal Power Solution: 12+1 power stages with ProCool power connectors, high-quality alloy chokes and durable capacitors to support multi-core processors
• Optimized Thermal Design: Integrated I/O cover, VRM heatsinks with high conductivity thermal pads, and three onboard M.2 heatsinks
• High-performance Networking: On-board Intel® WiFi 6 (802.11ax) and Intel 2.5 Gb Ethernet with ASUS LANGuard
• Best Gaming Connectivity: Supports HDMI® 2.1 and DisplayPort™ 1.4 output, three M.2 slots, as well as USB 3.2 Gen 2×2 Type-C®
• Intelligent Control: ASUS-exclusive AI Cooling, AI Networking and Two-Way AI Noise Cancelation to simplify setup and improve performance
• DIY Friendly Design: M.2 Q-Latch, pre-mounted I/O shield, BIOS FlashBack™ button and Q-LED
• Unmatched Personalization: ASUS-exclusive Aura Sync RGB lighting, including one RGB header and three addressable Gen 2 headers
• Industry-leading Gaming Audio: ALC4080 with Savitech SV3H712 amplifier, along with DTS® Sound Unbound™ and Sonic Studio III
• Renowned Software: Bundled 60-day free trial of AIDA64 Extreme, and an intuitive UEFI BIOS dashboard with integrated MemTest86
