Asus RT-AC86U AC2900 Dual-Band Wireless Gigabit Router

Description

Network Standard

IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6

Product Segment

AC2900 ultimate AC performance: 750+2167 Mbps

Coverage

Very large homes

Data Rate

802.11a : 6,9,12,18,24,36,48,54 Mbps

802.11b : 1, 2, 5.5, 11 Mbps

802.11g : 6,9,12,18,24,36,48,54 Mbps

802.11n : up to 450 Mbps

802.11ac : up to 1734 Mbps

1024QAM (2.4GHz) : up to 750 Mbps

1024QAM (5GHz) : up to2167 Mbps

Antenna

External antenna x 3

Internal 3dBi antenna x 1 for Wi-Fi

Transmit/Receive

MIMO technology

2.4 GHz 3 x 3

5 GHz 4 x 4

Processor

1.8 GHz dual-core processor

Memory

256 MB Flash

512 MB RAM

Wi-Fi Technology

Beamforming: standard-based and universal

1024-QAM high data rate

20/40/80 MHz bandwidth

Operating Frequency

2.4 GHz / 5 GHz

Encryption

64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support

Firewall & Access Control

Access control?Parental control, Network service filter, URL filter, Port filter

Management

UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log

VPN Support

IPSec Pass-Through

PPTP Pass-Through

L2TP Pass-Through

PPTP server

OpenVPN server

PPTP client

L2TP client

OpenVPN client

WAN Connection Type

Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP

Utilities

Router setup wizard; Firmware restoration; Device discovery; printer setup utility

Ports

RJ45 for Gigabits BaseT for WAN x 1, RJ45 for 10/100/1000/Gigabits BaseT for LAN x 4

USB 2.0 x 1

USB 3.0 x 1

Features

MU-MIMO

Traffic Analyzer

Adaptive QoS

WTFast Gamers Private Network

AiProtection

Parental Control

Guest Network : 2.4 GHz x 3, 5 GHz x 3

Mac OS Backup

Enhanced media server (AiPlayer app compatible)

– Image : Jpeg

– Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg

– Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov

AiCloud personal cloud service

3G/4G data sharing

Printer Server

– Multifunctional printer support (Windows only)

– LPR protocol support

Download Master

– Support bt, nzb, http, ed2k

– Support encryption, DHT, PEX and magnet link

– Upload and download bandwidth control

– Download scheduling

AiDisk file server

– Samba and FTP server with account management

IPTV support

Roaming Assist

Button

WPS Button, Reset Button, Power Button, Wireless on/off Button, LED on/off Button

LED Indicator

Power x 1

Wi-Fi x 2

WAN x 1

WPS x 1

LAN x 4

Power Supply

AC Input : 110V~240V(50~60Hz)

DC Output : 19 V with max. 1.75 A current

OS Support

Windows 10

Windows 8

Windows 7

Mac OS X 10.6

Mac OS X 10.7

Mac OS X 10.8

Linux

Dimensions

220 x 160 x 83.3 ~ mm (WxHxD) (Without Bezel)

Weight

872 g

Operation mode

Wireless router mode

Access point mode

Media bridge mode
