Asus RT-AX88U AX6000 Dual Band Wireless Router

Description

• Network Standard
  IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IPv4, IPv6
• Product Segment
  AX6000 ultimate AX performance
• Coverage
  Very large homes
• Data Rate
  802.11ac (5GHz) : up to 4333 Mbps
  802.11ax (2.4GHz) : up to 1148 Mbps
  802.11ax (5GHz) : up to 4804 Mbps
• Antenna
  External antenna x 4
• Transmit/Receive
  2.4 GHz 4 x 4
  5 GHz 4 x 4
• Processor
  1.8 GHz quad-core processor
• Memory
  256 MB Flash
  1 GB RAM
• Wi-Fi Technology
  OFDMA (Orthogonal Frequency Division Multiple Access)
  Beamforming: standard-based and universal
  1024-QAM high data rate
  20/40/80/160 MHz bandwidth
• Operating Frequency
  2.4 GHz / 5 GHz
• Encryption
  WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support
• Firewall & Access Control
  Firewall: SPI intrusion detection, DoS protection
  Access control：Parental control, Network service filter, URL filter, Port filter
• Management
  UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log
• VPN Support
  IPSec Pass-Through
  PPTP Pass-Through
  L2TP Pass-Through
  PPTP server
  OpenVPN server
  PPTP client
  L2TP client
  OpenVPN client
• WAN Connection Type
  Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
• Utilities
  Router setup wizard; Firmware restoration; Device discovary; printer setup utility
• Ports
  RJ45 for BaseT for WAN x 1, RJ45 for BaseT for LAN x 8
  USB 3.1 Gen 1 x 2
• Features
  Link Aggregation
  – 802.3ad
  MU-MIMO
  Traffic Analyzer
  Adaptive QoS
  WTFast Gamers Private Network
  AiProtection Pro
  Parental Control
  Guest Network : 2.4 GHz x 3, 5 GHz x 3
  VPN server : PPTP Server, OpenVPN Server, IPSec server
  VPN client : PPTP client, L2TP client, OpenVPN client
  NAT Pass-Through :PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay
  Mac OS Backup
  Enhanced media server (AiPlayer app compatible)
  – Image : Jpeg
  – Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg
  – Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
  AiCloud personal cloud service
  3G/4G data sharing
  Printer Server
  – Multifunctional printer support (Windows only)
  – LPR protocol support
  Download Master
  – Support bt, nzb, http, ed2k
  – Support encryption, DHT, PEX and magnet link
  – Upload and download bandwidth control
  – Download scheduling
  AiDisk file server
  – Samba and FTP server with account management
  Dual WAN
  IPTV support
  Roaming Assist
• Button
  WPS Button, Reset Button, Power Button, Wireless on/off Button, LED on/off Button
• LED Indicator
  Power x 1
  Wi-Fi x 2
  WAN x 1
  LAN x 1
  USB x 2
  WPS x 1
• Power Supply
  AC Input : 110V~240V(50~60Hz)
  DC Output : 19 V with max. 2.37 A current
• OS Support
  Windows® 10
  Windows® 8
  Windows® 7
  Mac OS X 10.6
  Mac OS X 10.7
  Mac OS X 10.8
• Dimensions
  11.8 x 7.4 x 2.4 ~ ” (Without Bezel)
