EVGA 700BR 700watts 80 Plus Bronze Power Supply

EVGA 700BR 700watts 80 Plus Bronze Power Supply

Product Specifications

• Brand: EVGA
• Model: 700BR
• CABLE LENGTH
• ATX Cable: 1x 550mm
• EPS Cable: 1x 600mm
• PCIE Cable: 2x 550mm, 670mm
• SATA Cable: 3x 450mm, 570mm, 690mm
• Four-Pin Peripheral Cable: 1x 450mm, 570mm, 690mm + 810mm (Floppy)
• Floppy Adapter: 1x
• AC Power: 1x 1200mm (m)
• Modular Cable Type: No
• CONNECTOR QUANTITY
• 24 Pin ATX: 1x
• EPS (CPU): 1x 8pin (4+4)
• PCIE: 4x 8pin (6+2)
• SATA: 9x
• Four-Pin Peripheral: 3x
• Floppy: 1x
• POWER SPECS
• AC Input: 100 – 240 VAC, 10/5A, 50 – 60 Hz
• Rail: +3.3V +5V +12V +5Vsb -12V
• Max Output: 24A 20A 3 3A 0.3A
• 6W
• 150W 6W 15W 3.6W
• Total: 700W @ +30C
• ADDITIONAL DETAILS
• Operating Temperature : 0° to 30° C
• Japanese Capacitors: No
• ECO Mode: No
• MTBF: 100,000 Hours
• Net Weight: 4 lbs
• Size: 85mm (H) x 150mm (W) x 140mm (L)
• Approvals: TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
• Compliance with ErP Lot 6 2013 Requirement
• Fan Size / Bearing: 120mm Long Sleeve Bearing
