Inno3D iChill NVIDIA® GeForce RTX™ 3080 X4 Gaming Videocard 10gb 320bit GDdr6X

47,352.00

Graphics Processor GPU Name GA102 GPU Variant GA102-200-K1-A1 Process Size 8 nm Transistors 28,000 million Die Size 628 mm² Graphics Card Generation GeForce 30 Bus Interface PCIe 4.0 x16 Clock Speeds Base Clock 1440 MHz Boost Clock 1710 MHz Memory Clock 1188 MHz 19 Gbps effective Memory Memory Size 10 GB Memory Type GDDR6X Memory Bus 320 bit Bandwidth 760.3 GB/s Render Config Shading Units 8704 TMUs 272 ROPs 96 SM Count 68 Tensor Cores 272 RT Cores 68 L1 Cache 128 KB (per SM) L2 Cache 5 MB Theoretical Performance Pixel Rate 164.2 GPixel/s Texture Rate 465.1 GTexel/s FP16…

Out of stock

Description

Graphics Processor
GPU Name GA102
GPU Variant GA102-200-K1-A1
Process Size 8 nm
Transistors 28,000 million
Die Size 628 mm²
Graphics Card
Generation GeForce 30
Bus Interface PCIe 4.0 x16
Clock Speeds
Base Clock 1440 MHz
Boost Clock 1710 MHz
Memory Clock 1188 MHz
19 Gbps effective
Memory
Memory Size 10 GB
Memory Type GDDR6X
Memory Bus 320 bit
Bandwidth 760.3 GB/s
Render Config
Shading Units 8704
TMUs 272
ROPs 96
SM Count 68
Tensor Cores 272
RT Cores 68
L1 Cache 128 KB (per SM)
L2 Cache 5 MB
Theoretical Performance
Pixel Rate 164.2 GPixel/s
Texture Rate 465.1 GTexel/s
FP16 (half) performance 29.77 TFLOPS (1:1)
FP32 (float) performance 29.77 TFLOPS
FP64 (double) performance 930.2 GFLOPS (1:32)
Board Design
Slot Width Dual-slot
TDP 320 W
Suggested PSU 700 W
Outputs 1x HDMI
3x DisplayPort
Power Connectors 1x 12-pin
2x 8-pin
Board Number PG132 SKU 10
Graphics Features
DirectX 12 Ultimate (12_2)
OpenGL 4.6
OpenCL 2
Vulkan 1.2
CUDA 8.5
Shader Model 6.5

Additional information

Weight 3.02 kg
